Smartphone camera ELITE
Pros and cons : Smartphone camera ELITE
- Camera facing forward so you can film while the phone is lying down.
- Direct image via phone screen
- Plug & Play
- Compact design
- Watch via another Android smartphone or PC
- Remote monitoring is not possible via an iOS device. However, via Android Smartphone and PC.
Description: Smartphone camera ELITE
This special camera is built into the front of the housing of an Android Smartphone. An App is installed on the phone that makes it possible to watch live from another location via another smartphone or PC. The images can also be recorded directly on the smartphone and viewed and played back on the screen.
How does the smartphone camera work:
In addition to the normal camera of the smartphone, an extra small camera has been placed on the front of the housing. We have installed an APP on the smartphone itself with which the images can be viewed immediately and possibly recorded on the phone memory. Watching from another location is possible by using certain PC software or installing an App on another Android smartphone.
Watch live via an Android App:
When a certain App is installed on an Android smartphone other than the included one, as stated in the manual, it is possible to watch the images live from that phone.
Watch live via a PC:
When certain software is installed on a PC as stated in the manual, it is possible to watch live measurements from that PC with the images.
Server costs for remote viewing:
For remote viewing, a server from the supplier which is located in Taiwan is used. There are costs associated with the use of this server. The first year is free of charge, but for further years a fee of 99.95 per year is charged incl. VAT. This is optional and does not concern a subscription, but must be paid before the end of the year if desired (pre-paid).
Different smartphone models available:
The smartphone camera shown and in stock with us is a Samsung S7 model. This solution can also be made to order in other Android smartphone models. You can request a quote from us for this.
Features Smartphone DVR:
1/6" Color CMOS Hidden Camera
Image area(mm): 2.7288x1.5498
Pixel Size(um): 1.4x1.4
Image Transfer Rate:
1920x1080@ 30fps MJPG/ 3fps YUV
1280x720@ 30fps MJPG/ 12fps YUV
640x480@ 30fps MJPG/ 30fps YUV
320x240@ 30fps MJPG/ 30fps YUV
Dynamic range: 73.3 dB @ 15.5x gain
Sensitivity: 553 mV/(Lux-sec)
Lens: 1.83mm/F2.0 (M4xP0.2)
H=70; V=42.7; D=77.3
Focus distance: infinity
Power: DC5V, 150mA(Max)
OS Support: MAC OS, Windows10, Windows8,
Windows7, Windows XP, Linux, Android
Cable length: 110cm (OD2.8mm)
Connector: Micro USB
1 x Smartphone camera model S7
1 x Year Access to Server
1 x Luxury Carrying Case
Specifications: Smartphone camera ELITE
|Camera type:||Camera set wired, 3G/4G camera|
|Resolution:||1920 x 1080 (Full HD)|
|View angle:||60 - 75 °|
|Filming through glass:||No|
|Looking from a distance:||Yes|
|Software / APP:||Android|
|Recording function:||SD card|
|Max. memory:||128 GB|
|Meegeleverd geheugen:||32 GB|
|Battery type:||Li-ion recharchable|
|Battery working time:||3 - 8 hours|
